Cnc Press Brake Machine Aluminum Composite Panels Bending Machine

A CNC press brake machine for aluminum composite panels bending is a sophisticated piece of equipment that is designed to bend and shape aluminum composite panels with great precision and accuracy. The machine uses advanced computer numerical control (CNC) technology to control the bending process, resulting in precise and accurate bends that meet the exact specifications of the design.

Aluminum composite panels are widely used in the construction industry as cladding material for buildings, facades, and signage. These panels are composed of two aluminum sheets that are bonded to a non-aluminum core, which gives them strength and rigidity. The panels need to be bent to fit the contours of the building or sign, which requires specialized equipment such as a CNC press brake machine.

The CNC press brake machine for aluminum composite panels bending is designed to handle a variety of panel sizes and thicknesses. The machine is equipped with a set of specialized tooling that is designed to bend the panels in specific shapes and angles. The tooling can be quickly changed to accommodate different panel sizes and shapes, making the machine highly versatile.

One of the benefits of using a CNC press brake machine for aluminum composite panels bending is the precision and accuracy of the bends. The machine is capable of making consistent and accurate bends, which ensures that the panels fit together perfectly and look aesthetically pleasing. The CNC control also allows for complex bending sequences and shapes, making it possible to create intricate designs and patterns.

Another benefit of the CNC press brake machine for aluminum composite panels bending is the speed and efficiency of the process. The machine can handle high-volume production runs, which means that large quantities of panels can be produced quickly and efficiently. This is ideal for construction projects that require a large number of panels to be installed in a short amount of time.

In conclusion, the CNC press brake machine for aluminum composite panels bending is a sophisticated piece of equipment that is designed to bend and shape aluminum composite panels with great precision and accuracy. The machine is highly versatile, efficient, and reliable, making it an ideal solution for construction companies and signage manufacturers that require high-quality panels that meet exact specifications.

Quick Description

• Slider Stroke (mm): 1800 mm
• Automatic Level: Fully Automatic
• Throat Depth (mm): 175 mm
• Machine Type: Synchronized
• Length of Working Table (mm): 2500
• Width of Working Table (mm): 1250 mm
• Condition: New
• Place of Origin: Anhui, China
• Material / Metal Processed: Brass / Copper, Stainless steel, ALLOY, Carbon steel, Aluminum, Plastic, PVC
• Automation: Automatic
• Weight (KG): 8000
• Motor Power (kw): 45 kw
• Key Selling Points: High-accuracy
• Warranty: 1 Year
• Applicable Industries: Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Advertising Company
• Showroom Location: Egypt, United Kingdom, Viet Nam, India, Mexico, Thailand, Sri Lanka, Malaysia
• Marketing Type: New Product 2020
• Machinery Test Report: Provided
• Video outgoing-inspection: Provided
• Warranty of core components: 24 months
• Core Components: Bearing, Motor, Pump, Gear, PLC, Pressure vessel, Engine, Gearbox
• Power: CNC
• Name: Panel Bending Machine
• Number of axes: 11/12 optional
• Model: DA52S
• Application: for press brake
• Bending angle: 0-180°
• Dimension: 3370*1890*2650
• Minimum arc radius: 1.2mm
• The fastest continuoue bending speed: 0.2s
• Type: CNC Hydraulic

More Details

Product Description

The intelligent flexible bending center focuses on solving various complex sheet metal bending problems in metal forming. Mainly engaged in the research and development, production and sales of intelligent flexible bending centers, self-propelled robotic arms, multi-axis concurrent linkage control systems, and cloud operation and maintenance management platforms.

RAYMAX have independent intellectual property rights, and realize the real 9-axis concurrent linkage. Each single control board supports 32-axis concurrent linkage, which can realize infinite cascade. Products have been widely used in file cabinets, electrical cabinets, kitchen utensils, fixtures, decoration, ventilation, refrigeration, elevators, car industry, door industry and other metal forming fields.

Compared with traditional hydraulic bending advantages:

1. The processing speed is fast, up to 0.2 seconds/knife;
2. High precision, can reach 0.1mm-0.2mm, the machine is equipped with 15 axes as standard, realizing full automation of complex workpieces.
3. The machine is easy to operate, and one worker can operate multiple devices.
4. The bed is made of castings, with good stability and mature technology, and the machine can be used for a long time to ensure high precision.

Casting!

Casting machine structure and machine body, which ensures machine stable and no shape change for long years use. machine with heat treatment!

Main function configuration:

High-grade casting
9-axis concurrent linkage control system
C axis lift (sucker type)
Double C-axis automatic following system (press arm type)
Graphic visualization error detection programming
Oil supply self-lubricating system
Double Y-U automatic positioning ruler (press arm type)
Workpiece anti-misplacement detection function (press arm type)
Custom function of workpiece precision surface
0.001mm system accuracy
Eccentric load detection system
Plate thickness detection system
Eccentric load bending follow system
Interchangeable and customized narrow module (sucker type)
Cloud operation and maintenance management interface
Y-axis double leaning ruler (sucker type)
Offline editing function
Big data self-learning function
Advanced programming functions
High-speed control module
Up and down pressing dead edge function
Flattening function
Self-driven loading and unloading integrated automation components
Handwheel function

Detailed Images

RAYMAX patented tooling die

RAYMAX patented design of the tooling die, which is friendly to stainless steel. there will be no trace left on the plate surface, to ensure the perfect bending effect.

The upper and lower bending Tool (A, D) perform upward or downward bending during work.

The upper pressing tool (B) works simultaneously with the bending tool and the lower pressing tool

Precise and efficient fixing and bending of sheets.

The lower pressing tool (C) clamps the sheet during bending.

Imported slow wire technology, higher consistency, the precision of the general segment upper pressing tool can reach 0.006mm, to achieve real bending without indentation, the overall heat treatment and ultra-cryogenic process have higher hardness and wear resistance.

Using cr12mov or 42crmo material, different materials can be selected according to customer process.

Self-built tool factory, each tool can be traced back to the source, and passed strict quality inspection, the quality is more guaranteed.

Full automatic type CNC robot

To match with CNC robot arm, realize the full automatic plate loading and work piece unloading. The ensure the most effective and save labor cost !

Automatic loading and unloading technology solution:
The system reserves abundant industry 4.0 .
The interface can be connected to the robot arm to realize automatic loading and unloading.

Equipped with RAYMAX self-propelled robotic arm, it has the same control system as the bending center. There is no need for secondary programming to replace workpieces. The system automatically generates robotic arm movements according to the bending instructions, with higher efficiency and better coordination.
